- Functional Description
- Specifications
- Applications
1. This series of spotlight lamp is made from exuded aluminum with excellent heat-dissipation effect, good light transmittance ratio glass mask and high light efficacy as well as wide vision angle.
2. Employ middle-power LED light source with single color or multiple color light source, abundant color changes available and good color saturation, suitable for the décor lighting in and outside.
3. Employ on-line DMX512 patent technology 【patent number：ZL 2010 2 0262526.4：ZL 2009 1 0223737.9】
4. To write the address in the controlling end after finishing the lamp installation, more convenient installation and better reliability.
5. Fully-concealed structure reaching IP65 protection grade ,easy installation suitable for use in and outside.
技術分類Technical?Classification | 項目規格 Item | 參數 Parameter |
電氣性能Electrical?Properties | 供電電壓 Input?voltage | DC24V |
最大功耗 Max?power?consumption | 6W | |
光學性能Optical?Properties | 光源(yuan)組(zu)成 LED?composition | 24R+20G+16B直插?LED? ?24R+20G+16B?DIP?LED |
光色 LED?color | 紅色/綠色/藍色?全彩色 red/green/blue/full?color | |
面光強度(du) Brightness | 48cd/pcs | |
光束角 Beam?angle | 60°X110° | |
亮度等(deng)級 Brightness?grade | 每種顏色256?級 256?grade?percolor | |
光(guang)通維持率(lv) Luminous?maintenance?rate | 50000?hour（@70%） | |
控制方式Control?Mode | 控制接(jie)口 Interface | DMX512? |
控制系統(tong) Control?System | 中鳴科技 Easyplay5.0（joinmax） | |
結構性能Structure | 尺寸(長x寬x高)?Dimension(LxWxH) | Φ85mm×H36mm |
燈體(ti)材(cai)料 Material | 壓鑄鋁 Die-casting?aluminium | |
表面顏色 Surface?color | 米黃色（根據客(ke)戶(hu)需要定制） Beige | |
燈(deng)具連接 Connection | 6芯信號電纜，帶自動編址功能。 5-pin?signal?cable?automatic?addressing?function | |
防護等級 IP?grade | IP65 | |
工(gong)作溫度 Work?temperature | -20℃～50℃ | |
工作濕度 Work?humidity | 0～90% | |
最(zui)大級聯(lian)數 Max.?cascade?connection?qty | 總線最大負荷50個燈具?????? Up?to?50?fixtures | |
使用(yong)環境 Work?Environment | 干燥/潮濕 dry/wet | |
安全性能Safety | 認證 Certificate | CE |
發光顏色 ?LED?color | 產品編號 Model |
RGB? | JM02-106004RGB |
-
